How to calculate the weight per meter of cable trays
The weight of a cable tray per meter is calculated by multiplying the tray's material density by its volume and then dividing by the tray length, with additional weight from cables added separately.
Step 1: Determine Tray Material and Dimensions
Identify the material of the tray (e.g., galvanized steel, stainless steel, aluminum) and its density. Typical densities are:
- Hot-dip galvanized steel: 7,850 kg/m³
- Stainless steel 304: 7,930 kg/m³
- Aluminum 6063: 2,700 kg/m³ Measure the tray dimensions: width, height (sidewall depth), thickness, and length. For perforated trays, account for the open area, which reduces weight by 15–30% compared to solid trays .
Step 2: Calculate Tray Volume
The tray volume includes side rails, rungs, and cross-bars. For ladder trays, approximate the volume as the sum of the two side rails plus the average rung material per meter based on rung spacing . For solid trays, multiply the tray width, height, and thickness to get the metal volume.
Step 3: Multiply by Material Density
Weight of the tray = Volume × Material Density. This gives the empty tray weight. For example, a 6-meter galvanized steel ladder tray may have a dead load of 28.26 kg .
Step 4: Convert to Weight per Meter
Divide the total tray weight by its length to get the weight per meter: Weight per meter = Total tray weight ÷ Tray length To convert to pounds per foot, divide the weight per meter by 3.28084 .
Step 5: Add Cable Weight
Calculate the total weight of the cables to be installed. Consider:
- Cable type (copper is heavier than aluminum)
- Cable size and number of conductors
- Armored vs unarmored cables
- Fill percentage of the tray Add the cable weight per meter to the tray's empty weight to get the total structural load per meter .
Step 6: Include Accessories and Safety Factors
If the tray has covers, dividers, or junction boxes, include their weight. Apply a safety factor if required for installation or dynamic loads such as maintenance personnel, wind, or snow .
Summary Formula
Total weight per meter = (Tray volume × Material density ÷ Tray length) + Cable weight per meter + Accessories weight per meter This calculation ensures accurate load estimation for supports, hangers, and structural design, preventing overloading and ensuring safe installation.
